Nix Workshop 

Part 1: Nix, Flakes & Nix DevShell

Gabriel Nützi, gabriel.nuetzi@sdsc.ethz.ch

Cyril Matthey-Doret, cyril.matthey-doret@epfl.ch

May 8, 2025 (Updated: May 15, 2025), Repository, Slides

Help

How to use these slides:

  • S: See the speaker notes.
  • Esc: See all slides and jump around.
  • Space: Go forward.
  • Shift + Space: Go backward.

Acknowledgment

Thanks to the following contributors:

Requirements

All examples refer to the workshop repository in the root directory.

Ensure that you have installed Nix and direnv.

The basic requirements for working with this repository are:

  • just
  • nix

See instructions.

🪟 Windows Users: kindly asked to leave this presentation (since Nix is for Unix system) or use WSL Ubuntu.

Motivation

 Why Nix?

You start python and you get this:

>>> import numpy
Segmentation fault (core dumped)

💣 It Works on My Machine

🧪 Development Setups


Feature Local Development Mamba Devcontainer Nix/DevShell
Maintainenance ⚠️ High ⚡ Medium ⚡ Medium ⚡ Medium
Reproducibility ❌ Low ⚠️ Medium ⚡ Medium ✅ Very high
Ease of Use ❌ Low ✅ Easy ✅ Ok ⚠️ Medium
Dep. Mgmt. ❌ ✅ ⚡ ✅
Portability 💣 ⚠️ ✅ ✅
CI Stability 💣 ⚡ ⚡ ✅ Almost Perfect

Full Table

 What is Nix?

Nix is a software package management & deployment infrastructure:

  • 🏃🏻‍♂️Software is built and run in a predictable and reproducible way.

  • ✅ Builds are reproducible — same inputs give same results.

  • 🔄 Installs packages without breaking others.

  • 📦 Can create isolated dev environments.

  • 💻 Works on Linux, macOS.

Nix started 2006 …

Eelco Dolstra’s PhD Thesis

Learn Nix the Fun Way

Why I love Nix, and you should too! 💖

What Is My IP?

#! /usr/bin/env bash
curl -s http://httpbin.org/get | jq --raw-output .origin
12.24.14.88

What guarantees that jq or curl is available?

Build It With Nix (1)

{
  system ? builtins.currentSystem,
  pkgs ?
    import
      (builtins.fetchTarball "https://github.com/NixOS/nixpkgs/archive/9684b53175fc6c09581e94cc85f05ab77464c7e3.tar.gz")
      {
        inherit system;
      },
}:
pkgs.writeShellScriptBin "what-is-my-ip"
''
  ${pkgs.curl}/bin/curl -s http://httpbin.org/get | \
    ${pkgs.jq}/bin/jq --raw-output .origin
''

Build It With Nix (2)

Building this Nix code gives you a store path:

/nix/store/7x9hf9g95d4wjjvq853x25jhakki63bz-what-is-my-ip

which contains the script and all needed dependencies

#!/nix/store/mc4485g4apaqzjx59dsmqscls1zc3p2w-bash-5.2p37/bin/bash

/nix/store/zl7h70n70g5m57iw5pa8gqkxz6y0zfcf-curl-8.12.1-bin/bin/curl \
  -s "http://httpbin.org/get" | \
  /nix/store/y50rkdixqzgdgnps2vrc8g0f0kyvpb9w-jq-1.7.1-bin/bin/jq \
    --raw-output ".origin"

Nix has encoded the used executables with store paths (/nix/store).

Quiz: Can you share this script with your colleague?

What Is This Hash ?

/nix/store/7x9hf9g95d4wjjvq853x25jhakki63bz-what-is-my-ip

Seeing 7x9hf9g95d4wjjvq853x25jhakki63bz is an extremely strong guarantee of the built software down to the commit/version and build instructions including dependencies.

 The Nix Language

In a Nutshell

 The Nix Language

  • A domain-specific functional language (no side-effects).

  • Structurally similar to JSON but with functions.

  • Supports fundamental data types such as string, integer, path, list, and attribute set. See Nix Language Basics.

  • Lazy evaluated, expression evaluation delayed until needed.

  • ⚠️The Nix language is specifically designed for deterministic/reproducible software deployment.

 The Nix Language

  • Nix files have suffix .nix and contain mostly 1 function.

  • The function args: ... in file myfunction.nix takes one argument banana and

    # myfunction.nix
banana:
let
  aNumber = 1;  # A number.
  aList = [ 1 2 3 "help"];  # A list with 4 elements.
  anAttrSet = { a = 1; b.c.d = [1]; };  # A nested attribute set.
  result = banana.getColor { v = aNumber; };  # Calls another function `args.myFunc`.
in
{ x = aNumber; y = anAttrSet.b.c.d; z = result; }

    returns an attribute set { x = ... }.

  • Watch this short introduction for the basic building block.

Examples

Verify the next examples in the Nix REPL (interactive Nix shell):

nix repl

or pass std. input to nix eval:

echo '
  let a = 3; in a
' | nix eval --file -

In workshop repository:

echo '3' | just eval

Examples

let # start for "procedural" statements
 mult = a: b: a * b;
 x10 = mult 10; # Bind the first arg.
in
x10 (mult 8 2)
# -> 160
let
f = args: {
  a = args.banana + "-nice";
  b = args.orange + "-sour";
};
in
f { banana = "1"; orange = "2" }
# -> { a = "1-nice"; b = "2-sour"; }
let
f = { ban, ora, ...}: { # Destructuring
  a = ban + "-nice";
  b = ora + "-sour";
};
in
f { ban = "1"; ora = "2"; berry ="3"; }
# -> { a = "1-nice"; b = "2-sour"; }
let
f = list: {
  a = builtins.map (x: x*x) list;
};
in f [ 1 3 9 ]
# -> { a = [ 1 9 81 ] }

More Examples

# Concat lists.
[ 1 2 3 ] ++ [ 1 2 3 ]
# [ 1 2 3 1 2 3 ];
# Merge attribute sets.
{ a = 1; b = 2; } // { a = 2; c = 3; }
# -> { a = 2; b = 2; c = 3; }
rec {
  b = 2;
  c = b + d;
  d = 10;
}
# -> { b = 2; c = 12; d = 10; }
# Lazy evaluation.
let
  x = abort "fail";
in
if false then x else 42
# -> 42
# Import files.
let
  myfunc = import ./myfunction.nix;
in myfunc 1 + (import ./other.nix 3)

Attribute Set Building: inherit

# Inherit 'key = value'.
let
  width = 100;
  color = "blue";
  set = { b = 1; };
in
{
  inherit color;   # color = color;
  inherit (set) b; # b     = set.b;
}

Variable Interpolation

let
  key = "c"
  color = "blue";
  set = {
    c = { v = "hello-${color}" ;}
  };
in set.${key}.v

# -> "hello-blue"

Strings and Paths

let
  dir = ./.github/workflows;    # A path. Nix makes them absolute!
  file = "${dir}/gh-pages.yaml"; # Interpolated path gets added into the `/nix/store`.
in file
# -> "/nix/store/w9il9gvki2nfdzfc1lrlbiv3xy3mx90a-workflows/gh-pages.yaml"

Caution With let Statements

Do not reassign in let blocks:

let
  a = "hello";
  a = a + "world";
  #   ^
  #   |
  #  🆘 Endless recursion, this is not reassigning.
in a

✅ Configure nixd (Nix Language Server) in your IDE to see “Go to definitions”.

Exercises

Try out the before shown examples your self with nix repl.

Time: 10min

Appendix: Fixed Point Combinator 🤯

In maths a fix point x of a function F is defined as:

\[ x = F(x). \]

In functional programming a fix-point combinator fix is a higher-order function.
It returns the fix point of a function F:

fix = F: let x = F x in x

Appendix: Fixed-Point Combinator 🤯

That is how recursive self-referential sets can be defined.

let
  fix = F: let x = F x in x;

  # Define the constructor of the set.
  newSet = self: { path = "/bin"; full = self.path + "/my-app"; };

  mySet = fix newSet; # fulfills: mySet == fix mySet;
in
  mySet.full

Seems recursive in let x = F x but but isn’t 🤯, because its lazy evaluated. What you need to know about laziness..

Used in pkgs.callPackage in nixpkgs.

Appendix: Why Nix is Lazy Evaluated?

The choice for lazy evaluation allows us to write Nix expressions in a convenient and elegant style: Packages are described by Nix expressions and these Nix expressions can freely be passed around in a Nix program – as long as we do not access the contents of the package, no evaluation and thus no build will occur. […] At the call site of a function, we can supply all potential dependencies without having to worry that unneeded dependencies might be evaluated. For instance, the whole of the Nix packages collection is essentially one attribute set where each attribute maps to one package contained in the collection. It is very convenient that at this point, we do not have to deal with the administration of what exactly will be needed where. Another benefit is that we can easily store meta information with packages, such as name, version number, homepage, license, description and maintainer. Without any extra effort, we can access such meta-information without having to build the whole package. [Paper]

Workshop

Building Our First Package (1)

Put the following in a script whats-is-my-ip.nix:

{
system ? builtins.currentSystem, # Mostly: x86_64-linux
pkgs ?
  import (builtins.fetchTarball
    "https://github.com/NixOS/nixpkgs/archive/9684b53175fc6c09581e94cc85f05ab77464c7e3.tar.gz") {
    inherit system;
  },
}:
pkgs.writeShellScriptBin "what-is-my-ip" ''
  ${pkgs.curl}/bin/curl -s http://httpbin.org/get | \
    ${pkgs.jq}/bin/jq --raw-output .origin
''

Quiz: What returns builtins.fetchTarball "..." ?

Wait! What is https://github.com/NixOS/nixpkgs ?

  • 󰳏 The repository nixpgkgs is a giant mono-repository with Nix code to build over 130k software packages (derivations).

    • from basic C/C++ compiler (named stdenv) and infrastructure to bootstrap tools of any Linux (coreuitls etc.) up to

    • leaf-like packages like signal, firefox, etc.

  •  A commit on nixpkgs represents the version of all packages at that commit.

  • Importing default.nix, 1 from nixpkgs (see import) returns a function to instantiate this giant flat attribute set pkgs for your system.

  • Search packages here and more granular here.

Building Our First Package (2)

nix build -f ./examples/what-is-my-ip.nix --print-out-paths

> "/nix/store/7x9hf9g95d4wjjvq853x25jhakki63bz-what-is-my-ip"

Explore whats in /nix/store/7x9hf9g95d4wjjvq853x25jhakki63bz-what-is-my-ip/bin/what-is-my-ip:

#!/nix/store/mc4485g4apaqzjx59dsmqscls1zc3p2w-bash-5.2p37/bin/bash
/nix/store/zl7h70n70g5m57iw5pa8gqkxz6y0zfcf-curl-8.12.1-bin/bin/curl \
  -s "http://httpbin.org/get" | \
  /nix/store/y50rkdixqzgdgnps2vrc8g0f0kyvpb9w-jq-1.7.1-bin/bin/jq \
    --raw-output ".origin"

Building Our First Package (3)

pkgs.writeShellScriptBin "what-is-my-ip" ''
  ${pkgs.curl}/bin/curl -s http://httpbin.org/get | \
    ${pkgs.jq}/bin/jq --raw-output .origin
''

The pkgs.writeShellScriptBin is a trivial builder function around the fundamental derivation command (see ./examples/what-is-my-ip-orig.nix):

derivation {
  inherit system;

  name = "what-is-my-ip";
  builder = "/bin/sh";

  args = [
    "-c"
    ''
      ${pkgs.coreutils}/bin/mkdir -p $out/bin

      {
        echo '#!/bin/sh'
        echo '${pkgs.curl}/bin/curl -s http://httpbin.org/get | \
        ${pkgs.jq}/bin/jq --raw-output .origin'
      } > $out/bin/what-is-my-ip

      ${pkgs.coreutils}/bin/chmod +x $out/bin/what-is-my-ip
    ''
  ];

  outputs = [ "out" ];
}

Inspect the Dependency Graph

Run

nix-store --query --include-outputs --graph \
  $(nix build -f ./examples/what-is-my-ip.nix --print-out-paths) > graph.dot

dot -Grankdir=TB -Gconcentrate=true -Tpng graph.dot > graph.png

and inspect graph.png.

Exercise: Inspect the Dependency Graph

  • Reproduce the commands for building what-is-my-ip.nix on your machine in the workshop repository.
  • Inspect the store path.
  • Explore the dependencies and answer the quiz below:

Time: 15-20min

Quiz: What do you expect
/nix/store/zl7h70n70g5m57iw5pa8gqkxz6y0zfcf-curl-8.12.1-bin/bin/curl
links to and what does your system curl link to?

Use ldd to inspect.

Inspect the Dependency Graph

What Is a Flake?

You have seen files like flake.nix lying around in repositories already.

A flake.nix provides

  • a deterministic way to manage dependencies and configurations in Nix (Slide of the Nix Founder).

  • comes with a flake.lock file which locks dependencies.

Remember fetchTarball "..." in what-is-my-ip.nix which locks pkgs to a certain commit on the nixpkgs repository, a flake is a better way to manage locked inputs.

What Is a Flake (2)

A flake

  • references external Nix functions - called inputs.

    • Other repositories, local files, or URLs with a flake.nix.

  • defines structured outputs (a function)

    • Specifies what the flake provides.
{
  inputs = { /* ... */ };

  outputs = inputs: {
    packages = /* implementation */

    # ... other output attributes ...
  }
}

What Is A Flake? (3)

  • Nix can evaluate a flake.nix by calling the outputs function passing all inputs.

    • Try nix repl . to load all outputs of ./flake.nix in directory ..

    • Check outputs.packages.x86_64-linux = { ... }. It is a flat attribute set of Nix derivations.

What Is a Nix Derivation?

A derivation is a

  • specialized attribute set, describes how to build a Nix package.

    { type = "derivation"; ... }

    Check nix repl -f <nixpkgs> and type pkgs.curl.type.

Derivation Definition

A derivation is an instruction that Nix uses to realize a package. Created using a special derivation function in the Nix language, it can depend on multiple other derivations and produce one or more outputs. The complete set of dependencies required to build a derivation—including its transitive dependencies—is called a closure. [Ref]

Evaluating a Derivation

When Nix evaluates a derivation, it stores the result in the Nix store (/nix/store) as a store derivation (more details).

Inspect a Derivation

nix eval "./examples/flake-simple#packages.x86_64-linux.mytool"

> «derivation /nix/store/l8pma77py04gd5819zkk3h7jx0bgxqgm-mytool.drv»

./examples/flake-simple#packages.x86_64-linux.mytool is an installable. More later!

# Inspect the store derivation.
cat /nix/store/l8pma77py04gd5819zkk3h7jx0bgxqgm-mytool.drv

Inspect a Derivation (2)

> Derive([("out","/nix/store/5rvqlxk2vx0hx1yk8qdll2l8l62pfn8n-treefmt","","")],
[("/nix/store/1fmb3b4cmr1bl1v6vgr8plw15rqw5jhf-treefmt.toml.drv",["out"]),
("/nix/store/3avbfsh9rjq8psqbbplv2da6dr679cib-treefmt-2.1.0.drv",["out"]),
("/nix/store/61fjldjpjn6n8b037xkvvrgjv4q8myhl-bash-5.2p37.drv",["out"]),
("/nix/store/gp6gh2jn0x7y7shdvvwxlza4r5bmh211-stdenv-linux.drv",["out"])]
,["/nix/store/v6x3cs394jgqfbi0a42pam708flxaphh-default-builder.sh"]
,"x86_64-linux","/nix/store/8vpg72ik2kgxfj05lc56hkqrdrfl8xi9-bash-5.2p37/bin/bash",
["-e","/nix/store/v6x3cs394jgqfbi0a42pam708flxaphh-default-builder.sh"],
[ ("__structuredAttrs",""),("allowSubstitutes",""),
("buildCommand","target=$out/bin/treefmt\nmkdir -p \"$(dirname \"$target\")\"\n\nif [ -e \"$textPath\" ]; then\n  mv \"$textPath\" \"$target\"\nelse\n  echo -n \"$text\" > \"$target\"\nfi\n\nif [ -n \"$executable\" ]; then\n  chmod +x \"$target\"\nfi\n\neval \"$checkPhase\"\n"),("buildInputs",""),("builder","/nix/store/8vpg72ik2kgxfj05lc56hkqrdrfl8xi9-bash-5.2p37/bin/bash"),("checkPhase","/nix/store/8vpg72ik2kgxfj05lc56hkqrdrfl8xi9-bash-5.2p37/bin/bash -n -O extglob \"$target\"\n"),("cmakeFlags",""),("configureFlags",""),("depsBuildBuild",""),("depsBuildBuildPropagated",""),("depsBuildTarget",""),("depsBuildTargetPropagated",""),("depsHostHost",""),("depsHostHostPropagated",""),("depsTargetTarget",""),("depsTargetTargetPropagated",""),("doCheck",""),("doInstallCheck",""),("enableParallelBuilding","1"),("enableParallelChecking","1"),("enableParallelInstalling","1"),("executable","1"),("mesonFlags",""),("name","treefmt"),("nativeBuildInputs",""),("out","/nix/store/5rvqlxk2vx0hx1yk8qdll2l8l62pfn8n-treefmt"),("outputs","out"),("passAsFile","buildCommand text"),("patches",""),("preferLocalBuild","1"),("propagatedBuildInputs",""),("propagatedNativeBuildInputs",""),("stdenv","/nix/store/hsxp8g7zdr6wxk1mp812g8nbzvajzn4w-stdenv-linux"),("strictDeps",""),("system","x86_64-linux"),("text","#!/nix/store/8vpg72ik2kgxfj05lc56hkqrdrfl8xi9-bash-5.2p37/bin/bash\nset -euo pipefail\nunset PRJ_ROOT\nexec /nix/store/0jcp33pgf85arjv3nbghws34mrmy7qq5-treefmt-2.1.0/bin/treefmt \\\n  --config-file=/nix/store/qk8rqccch6slk037dhnprryqwi8mv0xs-treefmt.toml \\\n  --tree-root-file=.git/config \\\n  \"$@\"\n\n")])

JSON output of the above:

nix derivation show /nix/store/l8pma77py04gd5819zkk3h7jx0bgxqgm-mytool.drv

Inspect a Derivation ()

{
  "/nix/store/l8pma77py04gd5819zkk3h7jx0bgxqgm-mytool.drv": {
    "args": [
      "-e",
      "/nix/store/vj1c3wf9c11a0qs6p3ymfvrnsdgsdcbq-source-stdenv.sh",
      "/nix/store/shkw4qm9qcw5sc5n1k5jznc83ny02r39-default-builder.sh"
    ],
    "builder": "/nix/store/9nw8b61s8lfdn8fkabxhbz0s775gjhbr-bash-5.2p37/bin/bash",
    "env": {
      "__structuredAttrs": "",
      "allowSubstitutes": "",
      "buildCommand": "target=$out/bin/mytool\nmkdir -p \"$(dirname \"$target\")\"\n\nif [ -e \"$textPath\" ]; then\n  mv \"$textPath\" \"$target\"\nelse\n  echo -n \"$text\" > \"$target\"\nfi\n\nif [ -n \"$executable\" ]; then\n  chmod +x \"$target\"\nfi\n\neval \"$checkPhase\"\n",
      "buildInputs": "",
      "builder": "/nix/store/9nw8b61s8lfdn8fkabxhbz0s775gjhbr-bash-5.2p37/bin/bash",
      "checkPhase": "/nix/store/9nw8b61s8lfdn8fkabxhbz0s775gjhbr-bash-5.2p37/bin/bash -n -O extglob \"$target\"\n",
      "cmakeFlags": "",
      "configureFlags": "",
      "depsBuildBuild": "",
      "depsBuildBuildPropagated": "",
      "depsBuildTarget": "",
      "depsBuildTargetPropagated": "",
      "depsHostHost": "",
      "depsHostHostPropagated": "",
      "depsTargetTarget": "",
      "depsTargetTargetPropagated": "",
      "doCheck": "",
      "doInstallCheck": "",
      "enableParallelBuilding": "1",
      "enableParallelChecking": "1",
      "enableParallelInstalling": "1",
      "executable": "1",
      "mesonFlags": "",
      "name": "mytool",
      "nativeBuildInputs": "",
      "out": "/nix/store/blm702jzcwfppwrrj9925ivd9gxp4c9n-mytool",
      "outputs": "out",
      "passAsFile": "buildCommand text",
      "patches": "",
      "preferLocalBuild": "1",
      "propagatedBuildInputs": "",
      "propagatedNativeBuildInputs": "",
      "stdenv": "/nix/store/npp9k9062ny7w0k1i03ij6xvqb7vhvjh-stdenv-linux",
      "strictDeps": "",
      "system": "x86_64-linux",
      "text": "#!/nix/store/9nw8b61s8lfdn8fkabxhbz0s775gjhbr-bash-5.2p37/bin/bash\n\"/nix/store/xkk1gr9bw2dbdjna8391rj1zl1l3dmhq-cowsay-3.8.4/bin/cowsay\" \"Hello there ;)\"\necho \"-------------------------------------\"\n\"/nix/store/4ydiim4lfk6nyab4pdkjj9s33pgbigfd-figlet-2.2.5/bin/figlet\" \"Do you expect\"\n\"/nix/store/4ydiim4lfk6nyab4pdkjj9s33pgbigfd-figlet-2.2.5/bin/figlet\" \"something \"\n\"/nix/store/4ydiim4lfk6nyab4pdkjj9s33pgbigfd-figlet-2.2.5/bin/figlet\" \"useful ? \"\n\n"
    },
    "inputDrvs": {
      "/nix/store/1fsd2cb5ab7ci01ks4j0gbbq254jw6sk-stdenv-linux.drv": {
        "dynamicOutputs": {},
        "outputs": ["out"]
      },
      "/nix/store/lrf9kbhlaf5mkvnlf3zr9wzvk7c2z72l-bash-5.2p37.drv": {
        "dynamicOutputs": {},
        "outputs": ["out"]
      },
      "/nix/store/phq4wh4490manblg905xixpc3gvwr149-figlet-2.2.5.drv": {
        "dynamicOutputs": {},
        "outputs": ["out"]
      },
      "/nix/store/wdpicivrj0bmzh935rr1hm1vlk18j0mp-cowsay-3.8.4.drv": {
        "dynamicOutputs": {},
        "outputs": ["out"]
      }
    },
    "inputSrcs": [
      "/nix/store/shkw4qm9qcw5sc5n1k5jznc83ny02r39-default-builder.sh",
      "/nix/store/vj1c3wf9c11a0qs6p3ymfvrnsdgsdcbq-source-stdenv.sh"
    ],
    "name": "mytool",
    "outputs": {
      "out": {
        "path": "/nix/store/blm702jzcwfppwrrj9925ivd9gxp4c9n-mytool"
      }
    },
    "system": "x86_64-linux"
  }
}

Store Derivation

A derivation contains only build instructions for Nix to realize/build it. This can be literally anything, e.g. a software package, a wrapper shell script or only source files.

Build A Derivation

We can build the above derivation - or in other terms realize it in the Nix store - by doing:

nix build -L /nix/store/l8pma77py04gd5819zkk3h7jx0bgxqgm-mytool.drv --print-out-paths

or directly

nix build -L "./examples/simple-flake#packages.x86_64-linux.mytool" \
  --print-out-paths --out-link ./mytool

✅ Short Form: nix build "./examples/simple-flake#mytool" which uses builtins.currentSystem (works also for macOS users).

✅ Inspect tree ./mytool:

/nix/store/blm702jzc...vd9gxp4c9n-mytool
└── bin
    └── mytool

✅ Run it with:

./mytool/bin/mytool -h
nix run "./examples/flake-simple#mytool"

What Is an Installable

The path ./examples/flake-simple#packages.x86_64-linux.mytool is referred to as a Flake output attribute installable, or simply an installable.

An installable is a Flake output that can be realized in the Nix store.

  • ./examples/flake-simple refers to this repository’s flake.nix directory.
  • packages.x86_64-linux.mytool following # is an output attribute defined within the flake.

Most modern Nix commands accept installables as input, making them a fundamental concept in working with Flakes. You should only use the modern commands, e.g. nix <subcommand>. Stay away from the command nix-env.

Exercise

  • Load the flake in the the root directory in nix repl and use :lf .

    • Inspect the attribute inputs.nixpkgs.
    • Inspect the string "${inputs.nixpkgs}" and explore the output!
    • Try to explain import "${inputs.nixpkgs}" { system = "x86_64-linux"; }.

  • Eval/build/run the treefmt utility in the packages output in the flake inside the root directory.

    Hints:

    • nix eval --impure --expr 'builtins.currentSystem'
    • packages.${system}.treefmt
    • nix run
    • "github:sdsc-ordes/nix-workshop#..."

Time: 15-20min

What Is a DevShell?

Its a Nix derivation in the output attribute set devShells of the flake.nix:

{
  inputs = { /* ... */ };
  outputs = inputs: {
    packages = {
      mytool = /* derivation */
    };

    devShells = {
      banana-shell = /* derivation */
    };

    # ... other output attributes ...
  }
}

The banana-shell derivation is meant to be consumed by nix develop.

Create A DevShell

The flake in ./examples/flake-simple defines devShells an output:

 devShells = forAllSystems (system:
  let pkgs = inputs.nixpkgs-unstable.legacyPackages.${system}; in
  {
    default = pkgs.mkShell {
      packages = [ pkgs.skopeo pkgs.cowsay ];

      shellHook = ''
        echo "Hello from Shell"
        ${pkgs.cowsay}/bin/cowsay
      '';
    };
  }
);

Function pkgs.mkShell makes a derivation consumable by nix develop:

nix develop "github:sdsc-ordes/nix-workshop?dir=examples/flake-simple#default" --command zsh

Exercise: Modify the DevShell

Time: 15min

Use devenv.sh

Our best-practice repository templates support devenv.sh Nix DevShells.

  • Nix DevShells from nixpkgs (pkgs.mkShell) are quite raw and sometimes too simplistic.

  • Nix DevShells from devenv you can do a looot more stuff, better. To be continued …

  • They are configured based on the same mechanism which drives NixOS (NixOS Modules).

References

Your Nix Journey

  • ✅ Ask the people who set the devShell how to extend it if you don’t know yet.

  • ✅ Check the references.

  • More to come in part 2.

  • Changing the world of non-reproducible build systems is hard endeavour on its own.

  • Embrace Nix as tool to give you better reproducibility. The Nix community is always helpful.

Questions
